High Accuracy HRC Automatic Tube Mill

Brand Name : TengTian

Model Number : 150F

Certification : CE, ISO9001, BV

Place of Origin : Hebei

MOQ : 1 Set

Price : $100000 to $1 million

Payment Terms : L/C,T/T

Supply Ability : 50 Sets/Year

Delivery Time : 120 work days

Packaging Details : Export waterproof and Seaworthy packing.

Production Name : High Accuracy HRC Automatic Tube Mill

Applicable materials : Q345

Cutting method : cold saw

Product name : Full Automatic Tube Mill

speed : 75 m/min

Equipment Specification : customer specified

Forming method : Roller Squeeze

Warranty : One year

Material : Low carbon HRC

Key words : Automatic Tube Mill

Contact Now

High Accuracy HRC Automatic Tube Mill
High Accuracy HRC Automatic Tube Mill
Product Specifications
Attribute Value
Production Name High Accuracy Building Materials Steel Pipe Automatic Tube Mill
Applicable materials Q345
Cutting method Cold saw
Product name Full Automatic Tube Mill
Speed 75 m/min
Equipment Specification Customer specified
Forming method Roller Squeeze
Warranty One year
Material Low carbon HRC
Applications
  • Oil & Gas Pipes
  • Heating Pipe
  • Low-pressure Process Pipeline
  • Low Pressure Fire Fighting Pipeline
  • Sewage Pipes
  • Steel Scaffolding Pipe
  • Wire and Cable Protection Pipe
  • Structural Support Steel Pipe
  • Industrial Steel Pipes
  • Decoration Pipe
  • Water Pipe
  • Building pipe

High Accuracy HRC Automatic Tube Mill

Technical Overview
Feature Specification
After-sales Service Engineers available to service machinery overseas
Warranty 1 year
Certification ISO9001:2010
Application Decoration, Furniture, Household, Hand railing, Industrial area
Pipe Material Stainless steel / Carbon steel / Iron / Aluminum / Copper/ Galvanized
Type Pipe mill
Diameter 9-51mm
Thickness 0.2-1.5mm
Horizontal shaft 40mm
Vertical shaft 25mm
Pipe shape Round / Square / Rectangle
Welding type H-F welding
ERW Tube Mill Models
No. Model Size Thickness (mm) Roll Weight (mm) Forming Speed (m/min) Installed Capacity (kw)
1 200 20x20-50x50 1-3 5 20-80 900
2 600 60x60-150x150 2-7 10 20-60 1400
3 800 80x80-200x200 2.5-10 15 20-40 1600
4 1050 100x100-250x250 3-12.7 20 15-30 2600
5 1250 120x120-300x300 3-14 30 10-25 3200
6 1400 150x150-350x350 4-14 30 8-20 3600
7 1600 200x200-400x400 4-16 30 8-15 3900
8 2000 250x250-500x500 4-20 40 8-15 4200

High Accuracy HRC Automatic Tube Mill

Equipment Components
No. Component
1 Winding and unwinding reels
2 Straightener & leveler
3 Automatic shear and welding
4 Feeder and punching machine
5 Automatic forming and sizing part
6 Cutting machine
7 Via rollers
8 Automatic packing and palletizing
High Accuracy HRC Automatic Tube Mill

High Accuracy HRC Automatic Tube Mill

High Accuracy HRC Automatic Tube Mill

High Accuracy HRC Automatic Tube Mill

High Accuracy HRC Automatic Tube Mill

High Accuracy HRC Automatic Tube Mill

FAQ:

Q1: Are you manufacturer or trading company?
A1: we are manufactuer , more than 20 years experience.

Q2: What is the max size of pipe you have even produce?
A2: Max φ630mm

Q3:Can I visit your customer machine line?
A3: Yes, but I need to get agreement from my customer firslty.

Q4: what is your machine advantages?
A4:Contain Full automatic, Direct forming square, Share rollers. Fast change system

Q5:How I can get the quotation?
A5:Please send your requires of pipe size , thickness to us.
