HF Automatic Tube Mill for 114.3mm Round Pipe
Product Specifications
| Attribute | Value |
| Mill Name | Thickness 3.38mm-6.02mm Round Automatic Tube Mill Dia 114.3mm Include Rollers |
| Pipe material | Carbon Steel |
| After-sales service provided | On-Site Engineers |
| Voltage | 380V |
| Power | 1500KW |
| Speed | 20 - 60m / min |
| Pipe Shape | Round, Square & Rectangular |
| Round Pipe Diameter | 114.3mm |
| Warranty | 1 year |
Product Description
This automatic tube mill is designed to produce welded pipes of 33.4-114.3mm in diameter with wall thickness ranging from 3.38-6.02mm. Featuring an advanced roll pass design, the production line manufactures high-quality welded steel pipes with precision machining and assembly.
The HG114 production line incorporates a double-radius hole design, engineered to enhance operational characteristics, improve safety and production efficiency, while reducing roller costs.
Available Models
| Serial No. | Model | Thickness(mm) | Specification(mm) | Speed(m/min) | Main Engine(kw) | Power(kw) | Area |
| 1 | H20 | 0.3-1 | 8-20 | 30-120 | 55 | 60 | 7*50 |
| 2 | H32 | 0.3-2.0 | 12-32 | 30-120 | 75 | 100 | 7*50 |
| 3 | H50 | 0.8-2.5 | 16-50 | 30-110 | 110 | 150 | 7*60 |
| 4 | H60 | 0.8-3 | 20-60 | 30-100 | 132 | 200 | 7*65 |
| 5 | H76 | 1-3 | 12-76 | 30-100 | 320 | 250 | 8*80 |
| 6 | H89 | 1-4 | 32-89 | 30-80 | 350 | 300 | 8*80 |
| 7 | HG114 | 1.5-5 | 45-114 | 30-60 | 400 | 300 | 10*100 |
| 8 | HG165 | 3-7 | 60-165 | 30-50 | 600 | 400 | 10*110 |
| 9 | HG219 | 4-8 | 114-219 | 20-40 | 800 | 500 | 12*150 |
| 10 | HG273 | 4-10 | 114-273 | 15-30 | 1000 | 600 | 18*160 |
| 11 | HG325 | 4-12 | 165-325 | 10-30 | 1200 | 600 | 18*180 |
| 12 | HG426 | 4-16 | 165-426 | 8-25 | 1400 | 800 | 18*180 |
| 13 | HG508 | 4-20 | 219-508 | 8-20 | 2000 | 1000 | 21*180 |
Production Process
- Scroll up
- Uncoil
- Flattening
- End Shear & Butt Welding
- Accumulator
- Forming
- High-frequency induction welding
- Removing external burr
- Cooling
- Sizing
- Cutting
- Checking & Collecting
- Accessing Warehouse
Our Service
- On-site installation and operator training by our engineers
- One year quality guarantee with lifetime repair service
- Comprehensive pre-sales and after-sales support including workshop design and production output planning
- Option for extended engineer support (several months to 1 year) to optimize output and reduce costs
- Complete project design services for stainless steel and carbon steel pipe production
- Responsible for loading and shipping arrangements
FAQ :
Q1: Are you manufacturer or trading company?
A1: we are manufactuer , more than 20 years experience.
Q2: What is the max size of pipe you have even produce?
A2: Max φ630mm
Q3:Can I visit your customer machine line?
A3: Yes, but I need to get agreement from my customer firslty.
Q4: what is your machine advantages?
A4:Contain Full automatic, Direct forming square, Share rollers. Fast change system
Q5:How I can get the quotation?
A5:Please send your requires of pipe size , thickness to us.
